DE NEEF® waterproofing injection solutions
Leaks stop here: Fast, proven, durable.
The DE NEEF® portfolio provides waterproofing injection solutions that stop leaks under any circumstances and in any application--foundations, infrastructure and more. Nobody plans for a leak, so when one occurs it usually represents a cost overrun and a setback for a construction project. The ability to quickly and permanently stop a leak in any part of a construction is therefore invaluable for contractors and owners.
DE NEEF® Product Documents
Products
- Product Name
- Description
- Key Benefits
- Applications Type
Gelacryl Superflex AR is a 2-component polyacrylate gel. The A-component is a poly-acrylate resin, the B-component is a polymer blend. The 2-components are injected with a 2-component 1:1 ratio piston pump. Once polymerised, Gelacryl Superflex AR forms a resilient, highly elastomeric gel.
- Gelacryl Superflex AR injection systems are injected with a twin piston, 1/1 ratio pump.
- Exceptionally low viscosity. Gelacryl Superflex AR penetrates into cracks 0,1 mm wide.
- Excellent post-expansion properties in contact with water.
- Curtain grouting.
- Remedial repair of water leaks.
- Preventative waterproofing of structures.
- Water control during tunnelling operations.
- Waterproofing subterranean structures in concrete or masonry (cellars, underground car parks, etc.).
- Waterproofing cracks in concrete or rock.
- Waterproofing tunnel segments.
- Waterproofing tunnel liners.
- Expansion joints with small movement.
HA CUT CFL AF is a next generation 1- component injection resin with improved waterproofing and water cutting performance.
- ADR free transport.
- Next generation resin with improved waterproofing performance.
- Improved cell structure of the cured compound
- Designed for cutting off gushing water leaks
- Used to block leaks into diaphragm walls.
- Filling large voids
In its uncured form, HA Flex LV AF is a yellow, non-flammable liquid without phthalate plasticisers. HA Flex LV AF is a next generation 1-component injection resin with improved waterproofing performance.
- Complies with EN 1504-5, Principle D.
- ADR-free transport.
- Next generation resin with improved waterproofing performance.
- For stopping water leaks through joints between tunnel segments.
- For injection of the LDPE or HDPE membrane in tunnel constructions.
- For curtain injections behind tunnel segments
In its uncured form, HA Flex SLV AF is a yellow, non-flammable liquid without phthalate plasticisers. HA Flex SLV AF is a next generation 1-component injection resin with improved waterproofing performance.
- Next generation resin with improved waterproofing performance.
- Improved cell structure of the cured compound resulting in better mechanical properties and durability.
- Non-phthalate resin REACH compliant.
- For stopping water leaks through joints between tunnel segments.
- For injection of the LDPE or HDPE membrane in tunnel constructions.
- For curtain injections behind tunnel segments
HA SAFEFOAM™ NF is a single component, phthalate free, low viscosity, hydrophilic, polyurethane resin.
- ADR free transport
- Phthalate free resin, REACH compliant
- Non-flammable
- For sealing dry, moving, non-structural cracks
- For sealing moist, moving non-structural cracks
- For sealing water leaks between the joints of concrete tunnel segments
HA SOIL AF is a dark brown, non-flammable, low viscous liquid without phthalate plasticiser that expands and quickly (depending on temperature and the amount of HA Soil Cat AF catalyst used) cures to a rigid polyurethane foam.
- ADR free transport
- Next generation resin with improved performance
- Phthalate-free resins, REACH compliant
Used for stabilising loose soils or to increase the load bearing capacity of these soils.
Washing Agent Eco is a mixture of non-volatile, chlorine-free, non-toxic organic solvents for cleaning equipment and substrates of PU and epoxy resins, adhesives and paints.
- C Virtually non-flammable.
- Chlorine-free.
- Non-hazardous solvent.
Two-component epoxy resin, which cures into a rigid compound in wet and dry conditions.
- Insensitive to humidity.
- Cures in damp/wet environment.
- Low viscosity: deep penetration in the cracks.
- Low pressure injection for the structural bonding of cracks and microcracks in dry or wet concrete.
- Bonding and anchoring.
- Sealing of porous low density concrete.
- DE NEEF® Denepox 40 is not suited for applications in contact with moving water.
GELACRYL™ Superflex is a 2-component acrylic based hydrophilic resin, consisting of 2 components: a resin and an initiator which are pumped with a twin piston pump at a 1:1 ratio. Once polymerised, Gelacryl Superflex forms a resilient, highly elastic gel.
- Gelacryl Superflex is injected with a twin piston, 1:1 ratio pump.
- The exceptionally low viscosity allows Gelacryl Superflex penetrates cracks 0.1 mm wide.
- Large post-expansion in contact with water: approx. 150%.
- Curtain grouting.
- Injection of Re-Injecto and Re-Injecto LB re-injectable injection tubes.
- Repairing water leaks in structures under permanent water pressure.
- Preventative waterproofing of structures under permanent water pressure.
- Waterproofing of underground structures in concrete or masonry (cellars, underground car parks, etc.).
- Sealing of cracks in concrete.
- Waterproofing of tunnel liners.
DE NEEF® HA Cut AF is a next generation 1-component injection resin with improved waterproofing and water cutting performance.
- ADR free transport
- Next generation resin with improved waterproofing performance.
- Improved cell structure of the cured compound resulting in better mechanical properties and durability.
- Used to block water leaks in diaphragm walls.
- Filling large voids
- Injection of LDPE or HDPE membranes in tunnel construction
Seal leaks almost as fast as they appear
The major advantages of DE NEEF® products include the fact that they are easy to use, are not diluted and can be applied quickly and reliably. The portfolio is mostly based on single-component, closed cell, hydrophobic polyurethanes, which are both durable and lasting. Therefore, leaks that are stopped once will remain stopped. For taking care of leaks that slow down the progress of a job site, endanger the future of a construction, or prevent full use of a building, DE NEEF® has become the world's most trusted brand.
Solutions for every leak
DE NEEF® has a variety of formulations for a number of different applications:
- For owners who need to repair and maintain buildings and infrastructure projects
- For contractors who need to shore up deep foundations during excavation
- For installers and applicators who are charged with specialised leak repair
In every case, there's a DE NEEF® solution that's best-suited for the task at hand—including deep foundations, underground spaces, tunnels, mass rapid transport infrastructure and sewer repair applications.
Solutions for every structure
Concrete or masonry—no matter which type of construction, DE NEEF® can fix the leak. From the ground breaking through completion, DE NEEF® products can be used for soil injections and water control and remediation. DE NEEF® solutions can also be used during excavation or tunnel boring. DE NEEF® products can be used in every stage of underground construction.
Certified around the globe
We have done extensive testing of DE NEEF® products to ensure that performance claims are backed up in the field. DE NEEF® products have multiple certification levels including CE certification for use in the European Union, and have potable water certifications from around the world.
Supported globally, available locally
No two leaks are exactly the same—the only thing that any two leaks have in common is that they have to be fixed as fast as possible. The DE NEEF® portfolio offers solutions for all possible challenges in leak sealing and soil injections. With local availability, there's no waiting for the product to arrive—DE NEEF® is readily available.
With a global sales and technical support staff, contractors can trust that DE NEEF® solutions will perform. Don't wait for leaks to slow you down—contact GCP today to learn how to use DE NEEF® on your project.
Leaks Stop Here. Fast. Proven. Durable.
